Mounting Flange | Standard |
Shaft Style | Cylindrical |
Shaft Size | 32 mm |
Shaft Key | A10 x 8 x 45 mm (DIN6885) |
Port Style | Side port |
Port Dimension | G 1/2 |
Drain Port Style | Standard |
Drain Port Dimension | G 1/4 |
Painted | None |
Geometric Displacement | 200,0 [12.20] |
Max Inlet Pressure Cont | 230 [3340] |
Max Inlet Pressure Int | 295 [4280] |
Max Inlet Pressure Peak | 300 [4350] |
